Cones

Cones

[Image Description: A standard orange traffic cone]

Standard Traffic Cones

Features:

  • One piece, flow molded polyvinyl chloride
  • Anti-fade, flourescent orange color
  • Permanent stenciling if requested - additional fee
  • Broad base for stability
  • Heat resistance to 160 degrees
  • Elongation 200%
  • Tensile strength: 1200 psi minimum
  • Hardness: 80+-5 conical, 75+-5 base
  • Tear Strength: 250lbs psi

[Image Description: A person lifting an orange traffic cone] [Image Description: A standard orange traffic cone]
[Image Description: A diagram explaining what part of the cone the A, B, C, & D sizes refer to in the table below.]

Cone Specs

Model
Desc.
Thickness
 Top / Bottom
A
B
C
D
Height
Weight Lbs
Qty Per Carton
6PVCS Standard .056 .090 4-1/2" - 7/8" 2-1/4" 6" 1/4 200
12PVCS Standard .065 .120 8-1/4" 1-1/4" 2-3/16" 6-1/2" 12" 1-1/2 30
18PVCS Standard .065 .120 11-3/8" 1-1/4" 2-3/16" 7-1/4" 18" 3 20
18PVCH Heavy .070 .125 11-3/8" 1-1/4" 2-3/16" 7-1/4" 18" 4 20
18PVCX Xtra Heavy .080 .125 13" 1-1/4" 2-3/16" 7-1/4" 18" 7 14
28PVCS Standard .075 .130 14-1/4" 1-1/4" 2-3/16" 10-1/2" 28" 7 10
28PVCH Heavy .080 .135 15-1/4" 1-1/4" 2-3/16" 10-1/2" 28" 10 10
28PVCX Xtra Heavy .075 .130 15" 1-1/4" 2-1/2" 10-1/2" 28" 12 10
36PVCS Standard .075 .130 15" 1-1/4" 2-1/2" 10-1/2" 36" 10 10
36PVCH Standard .075 .130 15-1/2" 1-1/4" 2-1/2" 10-1/2" 36" 12 9
